KOYO CO. LTD. showcases its product catalog of vertical, horizontal, and combined molding machines.

KOYO SMS-7060RIII industrial molding machine

Molding Machine

Molding Machine

Vertical, horizontal and bimodal molding systems.

Molding Machine
Vertical Type SM-V series

Vertical Type

SM-V series

Molding Machine
Horizontal Type SMS series

Horizontal Type

SMS series

Molding Machine
Bimodal Type SM-60VH

Bimodal Type

SM-60VH

KOYO SM-60V Vertical Molding Machine
Vertical TypeKOYO

Vertical Type

KOYO Flaskless Vertical Molding Machine SM series

SM-50V-S / SM-50V-F / SM-60V-S / SM-60V-F / SM-70V

Our conception is to realize the following three performances:

  1. 01Improve Performance / Molding Capacity
  2. 02Save Running Cost
  3. 03Less Maintenance / Management

Specification

TYPESM-50V-SSM-50V-FSM-60V-SSM-60V-FSM-70V
MOLDING SIZEA Type: 500✕400✕100～315A Type: 600✕500✕180～330A Type: 720✕630✕180～350
B Type: 620✕500✕180～330B Type: 750✕600✕180～350
B Type: 500✕430✕100～315C Type: 600✕480✕180～330C Type: 770✕630✕180～350
D Type: 650✕535✕180～330
CAPACITY*300 Mold / h350 Mold / hA-C Type: 340 Mold / hA-C Type: 420 Mold / h350 Mold / h
D Type: 320 Mold / hD Type: 400 Mold / h

* 50V= at 150mm thickness without Core / 60V・70V= at 200mm thickness without Core

KOYO SMS-7060RIII horizontal molding machine
Horizontal TypeKOYO

Horizontal Type

KOYO Flaskless Horizontal Rotamatic Machine SMS-R series

KOYO Jacket Horizontal Rotamatic Machine SMS-RT series

Selectability among R-Ⅲ Flaskless line and RT-Ⅲ Jacket line

More filling by New Sand blowing control !!

Advantage in use of Rotormatic

  • ◯2-stations type by rotating Drag boxes
  • ◯Selectable Molding & Handling
  • ◯Easy Operation
  • ◯Spray effects inside of Mold Boxes

Specification

TYPESMS－5045RⅢ・SMS－5045RTⅢSMS－6050RⅢ・SMS－6050RTⅢSMS－7060RⅢ・SMS－7060RTⅢ
MOLDING SIZEUpper 500✕450✕160～200
Lower 500✕450✕160～200		Upper 600✕500✕160～200
Lower 600✕500✕160～200		Upper 700✕600✕160～250
Lower 700✕600✕160～250(RⅢ)
Lower 700✕600✕170～250(RTⅢ)
CAPACITY150 Mold / h (including Core set time 19 seconds)150 Mold / h (including Core set time 19 seconds)140 Mold / h (including Core set time 20 seconds)
KOYO Flaskless Bimodal Molding Machine SM-60VH
Bimodal TypeKOYO

Bimodal Type

KOYO Flaskless Bimodal Molding Machine SM-60VH

SM-60VH

Advantages in the use of SM-60VH

  1. 1. United the functions of Vertical & Horizontal Molding System and realized suitable production in Vertical and Horizontal as per the products.
  2. 2. Productive process can be constructed for Vertical and Horizontal Line One molding line.
  3. 3. Adapted KOYO Original Full No Flask & Pallet Molding System (Square Molding System) in both Vertical & Horizontal Mode.
Photo of the sprue cutter plate device
Sprue Cutter Plate Device
Photo of the partible mold chamber
Partible Mold Chamber
Photo of the mold swinging device
Mold Swinging Device
Photo of the box joining device
Box Joining Device

Specification

at Vertical Moldingat Horizontal Molding
MOLDING SIZE600✕500✕200～400Upper 600✕500✕160～200
Lower 600✕500✕145～200
CAPACITY300 Mold / h * (at 200mm thickness without Core)200 Mold / h * (at 160 / 160 mm thickness without Core)
